AXIstorage li sv1 energypack (3.37 kWh)
– Usable Capacity: 3.37 kWh
– Nominal Capacity: 74 Ah
– Charging Current: 37 A
– Discharge Current: 37 A
– Efficiency: up to 96 %
– Cooling: passive
– Range of Temperature: 0 – 50 °C
– Max. Air Humidity (not condensing): 95 %
– Technology: Lithium Iron Phosphate (LFP)
– Protection Category: IP55
– Certifications / Standards: VDE2510-50, IEC62619, IEC62477-1, IEC62040-1, CEC, CE, UN38.3
Type | Batteries |
Capacity | 3 KWh |
Efficiency | 96.0 % |
Voltage | n/a |
Voltage min | n/a |
Voltage max | n/a |
Measurements
length | 380 mm |
width | 600 mm |
Height | 170 mm |
weight | 36 kg |
Manufacturer warranty
Product warranty | 10 years |
Axitec Energy
Operations manual English SV1
Datasheet English SV1
Datenblatt German SV1
